ES-1304AKIT-DB2-5MP
Evtevision
ES-1304AKIT-DB2-5MP
【4CH 5MP DVR + 4Pcs 5MP HD Camera】5MP 8 Channel HD DVR surveillance recorder matches with outdoor/indoor 5MP 4 Pcs bullet cameras. BNC+DC CCTV cabling are more stable and reliable than wireless security system. 2560X1920 HD resolution DVR is equipped with HDMI/VGA port for multi video output. Using advanced H.265 video compression technology, it helps deliver much smoother video recordings and saves your HDD space
【Wide View & 60ft IR Night Vision Camera】3.6mm camera lens gives 90° wide viewing angle, with built-in infrared LED light for night vision up to 60ft, which could provide clear images even in night
【P2P Quick Remote Access】Surveillance DVR allows you to view the live streaming or playback video remotely by your phone and pad (Android & IOS). Just need connect to the internet and scan the DVR unique QR code to download free XMeye app
【Motion Detection & Instant Alert】When movements are detected, it will be recorded, you will receive email alerts with snapshot upon motion detection or App alert once you set. Easily record and playback on your mobile devices anywhere and anytime. In addition, you could use DVR to customize the detection area according to your requirement
【Multiple Recording/Playback Modes】You can customize your DVR with different recording modes including manual, schedule and motion detection. Various playback modes like event, tag and smart mode, are also available.
【4CH 5MP DVR + 4Pcs 5MP HD Camera】5MP 8 Channel HD DVR surveillance recorder matches with outdoor/indoor 5MP 4 Pcs bullet cameras. BNC+DC CCTV cabling are more stable and reliable than wireless security system. 2560X1920 HD resolution DVR is equipped with HDMI/VGA port for multi video output. Using advanced H.265 video compression technology, it helps deliver much smoother video recordings and saves your HDD space
【Wide View & 60ft IR Night Vision Camera】3.6mm camera lens gives 90° wide viewing angle, with built-in infrared LED light for night vision up to 60ft, which could provide clear images even in night
【P2P Quick Remote Access】Surveillance DVR allows you to view the live streaming or playback video remotely by your phone and pad (Android & IOS). Just need connect to the internet and scan the DVR unique QR code to download free XMeye app
【Motion Detection & Instant Alert】When movements are detected, it will be recorded, you will receive email alerts with snapshot upon motion detection or App alert once you set. Easily record and playback on your mobile devices anywhere and anytime. In addition, you could use DVR to customize the detection area according to your requirement
【Multiple Recording/Playback Modes】You can customize your DVR with different recording modes including manual, schedule and motion detection. Various playback modes like event, tag and smart mode, are also available.
Camera Specifications:
AHD mode camera
Image Sensor: 1/2.7〞CMOS CMOS with IR-Cut
Active Pixels: 2560(H)×1920(V)
Resolution: 5MP
85° Wide viewing angle
Lens: 3.6mm
IR LEDs Amount: 18Pcs
IR Distance: up to 60ft (20m)
Material: Aluminum
Weatherproof: IP66
DVR Specification:
5MP megapixel (2560X1920)
Menu Display:1/4/8 Screen
Video input: 4ch BNC interfaces
Video output: 1ch VGA and 1ch HDMI(4K HDMI Output)
Audio input/output: 1ch in/1ch out
Preview:4*5M@12fps
Record Resolution&Frame:4*5M@6fps,4*1080P@18fps
Playback Frame:2*5M@6fps,4*1080P@18fps
Record Mode: Manual, Alarm, Motion detection, Timing
Back up mode: Network, USB portable HDD,USB DVD-RW
1x SATA HDD interface(Max 6TB)
1x RJ-45 10M/100Mbps Network interface
2x USB 2.0 interface
Camera Specifications:
AHD mode camera
Image Sensor: 1/2.7〞CMOS CMOS with IR-Cut
Active Pixels: 2560(H)×1920(V)
Resolution: 5MP
85° Wide viewing angle
Lens: 3.6mm
IR LEDs Amount: 18Pcs
IR Distance: up to 60ft (20m)
Material: Aluminum
Weatherproof: IP66
DVR Specification:
5MP megapixel (2560X1920)
Menu Display:1/4/8 Screen
Video input: 4ch BNC interfaces
Video output: 1ch VGA and 1ch HDMI(4K HDMI Output)
Audio input/output: 1ch in/1ch out
Preview:4*5M@12fps
Record Resolution&Frame:4*5M@6fps,4*1080P@18fps
Playback Frame:2*5M@6fps,4*1080P@18fps
Record Mode: Manual, Alarm, Motion detection, Timing
Back up mode: Network, USB portable HDD,USB DVD-RW
1x SATA HDD interface(Max 6TB)
1x RJ-45 10M/100Mbps Network interface
2x USB 2.0 interface
Package Contents:
* 1x 8CH 5MP DVR
* 4x 5MP IR Dome Cameras
* 4x 5MP IR Bullet Cameras
* 2x DC12V Power Adapter
* 2x Power splitter cables
* 1x USB Mouse
* 8x 60Feet Video Cables
* 8x Mounting Screw bag
* 1x User Manual
Package Contents:
* 1x 8CH 5MP DVR
* 4x 5MP IR Dome Cameras
* 4x 5MP IR Bullet Cameras
* 2x DC12V Power Adapter
* 2x Power splitter cables
* 1x USB Mouse
* 8x 60Feet Video Cables
* 8x Mounting Screw bag
* 1x User Manual
