2MP Fisheye IP Cameras

Availability:



Inquire

Model:
ES-IPD203XSQF/A
Brand:
Evtevision

1080P HD Resolution;
Advanced H.265/ H.264 video compression;
1.8mm Fisheye Lens gives 135 degree wide viewing angle;
Built-in Audio;
Dual encoding streams supported;
Support Cloud service, by Device ID user can make remote access very easy;
Support Motion detection and JPEG image snapshot;
Free CMS, Built in Web Server;
Support Onvif;

1080P IP Camera Onvif Security Cameras Fisheye Lens Dome Camera

Camera Model	ES-IPD203XSQF/A
System	Embedded RTOS design
DSP	HI3516E V200
Image Sensor	1/2.7” SC4239P 2.0Megapixel
Effective Pixels	1920(H)*1080(V)
S/N Ratio	More than 58dB
IR Distance	None
Day/Night	Auto(ICR)/Color/B/W
Lens	1.8-12mm Fisheye lens
Video
Video compression	H.265/H.264 Compression Technology, AVI format
Resolution	1920*1080,1280×720
Video output	Main Stream:19201080@20fps,1280720@25fps Sub Stream:704*576@25fps
Video output	Stream 0.1M~10Mpbs adjustable, Frame 1 ~ 25fps adjustable
Bit Rate	H.264: 32K ~ 8192Kbps, MJPEG: 32K ~ 20480Kbps
Network
Ethernet	1* RJ45, 10/100M
Protocol	Support RTSP/FTP/DHCP/DDNS/NTP/UPnP
ONVIF	Support ONVIF 2.0/2.4
USB 3G&Wifi	No
POE	48V
Mobile phone	Support (iPhone /Android)
General
Basic Function	Motion detection, Web remote configuration, CMS software
Power Supply	DC12V
Power Consumption	<10W
Working Environment	-10°C~+60°C, 10%~90%
Application software	CMS/VMS platform network management software

Camera Model	ES-IPD203XSQF/A
System	Embedded RTOS design
DSP	HI3516E V200
Image Sensor	1/2.7” SC4239P 2.0Megapixel
Effective Pixels	1920(H)*1080(V)
S/N Ratio	More than 58dB
IR Distance	None
Day/Night	Auto(ICR)/Color/B/W
Lens	1.8-12mm Fisheye lens
Video
Video compression	H.265/H.264 Compression Technology, AVI format
Resolution	1920*1080,1280×720
Video output	Main Stream:19201080@20fps,1280720@25fps Sub Stream:704*576@25fps
Video output	Stream 0.1M~10Mpbs adjustable, Frame 1 ~ 25fps adjustable
Bit Rate	H.264: 32K ~ 8192Kbps, MJPEG: 32K ~ 20480Kbps
Network
Ethernet	1* RJ45, 10/100M
Protocol	Support RTSP/FTP/DHCP/DDNS/NTP/UPnP
ONVIF	Support ONVIF 2.0/2.4
USB 3G&Wifi	No
POE	48V
Mobile phone	Support (iPhone /Android)
General
Basic Function	Motion detection, Web remote configuration, CMS software
Power Supply	DC12V
Power Consumption	<10W
Working Environment	-10°C~+60°C, 10%~90%
Application software	CMS/VMS platform network management software
